Iron Tailing Recycling Machine HSJ

DESCRIBE
Applications:Tailing recycling machine is the ideal equipment for iron ore recycling plant to recovery iron powder from iron tailing. This equipment adopting a
DESCRIPTION

Applications:

Tailing recycling machine is the ideal equipment for iron ore recycling plant to recovery iron powder from iron tailing. This equipment adopting a unique arrangement of the magnetic field, features high efficiency in iron powder recycling, so the economic benefits of iron ore separating plant are greatly advanced.

Tailing recycling machine

Feature:

  1. Stable machine body, reasonable structure, easy to operate, convenient to maintain;
  2. Small power consumption, long service life;
  3. According to the delivery capacity of user's tailing, the recycling machine can be devided into 4 union, 6 union, 8 union, 9 union, 12 union, etc.
  4. There are many diameter options of the recovery disk for users to choose, including 800mm, 1000mm, 1200mm, 1500mm and so on.
Specifications & Technical Parameters
Model Specification Working Area
m2
Power
kW
Spindle Speed
RPM
Surface Magnetic Field
Gs
handling capacity
t/h
Weight
kg
HSJ0808 Φ800×8 12 5.5 1 1500 200 4500
HSJ1008 Φ1000×8 15 5.5 1 1500 240 5000
HSJ1508 Φ1500×8 20 5.5 1 1500 280 5500
HSJ1510 Φ1500×10 25 5.5 1 1500 350 5800
